A magnitude 6.5 earthquake struck Japan on Friday, causing widespread injuries and property damage. Then on Saturday evening, a magnitude 7.8 earthquake hit Ecuador on the other side of the Pacific, collapsing buildings and killing more than 350 people.
With two large earthquakes happening only days apart, it might look like they’re connected. But how earthquakes influence each other is rather complex, particularly over long distances.
Large earthquakes are caused by the rupture of faults that are a few tens of kilometres long for magnitude 7, to more than 1,000 kilometres for magnitude 9 and above.
The local perturbations caused by the sudden shift of rock mass across a large rupture results in a cascade of smaller earthquakes, called aftershocks, at distances roughly equivalent to the length of initial fault rupture. Aftershock rates peak immediately following the mainshock and decay exponentially with time.
However, if nearby faults are locked and already stressed, more damaging earthquakes may be triggered in the short term. The 2004 Sumatra magnitude (Mw) 9.2 and 2005 Mw 8.6 Nias earthquakes are the best known examples of short-term “clustering” of very large quakes.
Sumatran earthquake sequence for the 12 month period from 26/08/2004 to 25/08/2005 encompassing the 2004 Boxing Day Mw 9.2 and 2005 March Nias Mw 8.6 quakes. The y-axis shows each earthquake’s latitude. The initial 2004 Boxing Day ruptured some 1,300 kms northward from the initial rupture point near Banda Aceh (blue arrows), with aftershocks distributed all the way along the ruptured fault segment. The March 2005 Nias event ruptured an adjacent segment of the plate boundary to the south of the 2004 Boxing Day rupture, inducing a distinct aftershock sequence. In total almost 4,500 aftershocks of magnitude greater than 4 were recorded in the nine month period to late August 2005, of which about 560 were greater than 5. Note also how aftershock intensity tails off exponentially with time. Image by Mike Sandiford
A clear message from earthquake scientists to the public is that the most dangerous time for future large earthquakes in an affected region is immediately (within days to weeks) following a major earthquake.
The recent Nepal earthquakes in 2015 (Mw 7.8 and 7.3 within 17 days) provide further evidence for this.
Certainly, authorities in Ecuador, Panama, Colombia and Peru will be well aware of the importance of reiterating future hazards to the region posed by aftershocks, other strong earthquakes, tsunami, and other earthquake-triggered hazards in the aftermath of the Mw 7.8 earthquake on Saturday.
Remotely triggered earthquakes
But can earthquakes on one side of the globe trigger earthquakes on the other? And should we be concerned about the apparent global surge of earthquakes?
Large earthquakes send out seismic “shivers” that are recorded by seismographs around the globe. As these seismic surface waves pass through distant fault zones, they do occasionally trigger small earthquakes.
Scientists call this “remote triggering”. Some fault zones show evidence for “remote delayed triggering” several hours after the seismic surface waves from a large remote event pass through. However, a recent analysis indicates no compelling evidence for triggered events exceeding magnitude 5.
How long is too long before a local increase in earthquake activity can be linked to a preceding quake?
Therein lies a challenge that transcends seismic catalogues alone, requiring both rigorous statistical analysis and an analysis of the geologic conditions that could favour long time delays.
What we do know is that the transient stresses induced by large earthquakes are very small at remote distances, but perhaps not too small to influence the frequency of earthquakes in other regions.
What we also know is that the rate of global earthquakes is not steady. For example, the rate of large earthquakes since 2004 is more than double the rate averaged over the preceding century.
A similar cluster of large global earthquakes occurred between 1950 and 1965. To date, the reasons for the apparent multidecadal changes in seismic energy release rate remain poorly understood.
This map shows all earthquakes with a magnitude over 4.5 from the 11th-18th April. You can see that many earthquakes occurred around the Pacific during that period, but there are clusters around Japan and Ecuador following the large earthquakes there. USGS
Japan and Ecuador
The April 15, 2016, Mw 7.0 Japanese earthquake occurred as the result of strike-slip faulting. It was centred around 10km depth and ruptured an area around 50km long.
Effects of the Japanese earthquake include landslides, liquefaction, ground failure and building damage.
It was similar in style and dimensions of rupture and shaking to the 2010 Mw 7.1 Darfield earthquake near Christchurch New Zealand.
Aftershocks pose a major hazard, particularly to structures compromised by prior shaking. However, the Japanese earthquake occurred in a region that is frequently affected by seismic shaking from strong earthquakes, so the occurrence of this event should be no real surprise.
The April 16, 2016, Mw 7.8 earthquake offshore of the west coast of northern Ecuador occurred as the result of shallow thrust faulting on or near the plate boundary between the subducting Nazca and overriding South American tectonic plates.
The location and mechanism of the earthquake is consistent slip on the large thrust fault (i.e. megathrust), between these two major plates. The rupture length is estimated at 160km.
Earthquakes of this nature are relatively common in this region, even over historical timescales. The same plate boundary zone extending all the way along the western boundary of South America has produced the 1960 Valdivia quake – the largest ever recorded – and so again its rupture in Ecuador should be no particular surprise.
Any dynamic stresses induced by the Japanese earthquake at the site of the impending earthquake on the subduction zone west of Ecuador would pale in comparison to the local stresses accumulated from subduction of the Nazca plate, the relevant segment of which last ruptured in a large earthquake in 1942.
So the Japanese and Ecuador earthquakes were both large and damaging, and they occurred only days apart. This naturally triggers a great deal of media attention, and it’s easy to assume there is a link.
But the time delay between the Japanese and Ecuador events precludes any clear causal linkage on temporal grounds. Rather they are the natural consequence of the ongoing activity that surrounds the Pacific basin, in the so-called “ring of fire”, during a period of somewhat heightened seismic energy release.
